Zalman products have always stood out from the other heatsink manufacturers in performance and appeal. Their long line of quality coolers have been heralded by case modders and overclockers for sometime as quality performers without the associated noise levels. Zalman, ever striding for a completely noiseless system, continuously introduces new products such as coolers for the graphic chip, power supply, and of course, the CPU.

Specification:

• Heatsink Dimension: 109 (L) x 109 (W) x 62 (H) mm


• Dissipation Area: 3170 cm2


• Base Material: Pure Copper


• Rotational Speed: 1350 RPM +/- 10% (Silent) / 2400 RPM +/- 10% (Normal)


• Noise Level: 20 dBA +/- 10% (Silent) / 25 dBA +/- 10% (Normal)


• Bearing Type: 2-Ball


• Fan Mate Dimension: 200 (L) x 23 (W) x 21 (H) mm

Supported CPU:

• Intel Pentium4 Socket478 up to 3.06GHz

For an interactive installation guide, please visit ZALMAN at:

http://www.zalman.co.kr/images/swimages/2003/7000.swf

For a list of motherboards that interfere with the CNPS7000, please visit ZALMAN at:

http://www.zalman.co.kr/english/news/20030224.htm

IMPORTANT: 450g is the specified maximum weight for an Intel Pentium 4 cooler. The weight of CNPS7000-Cu is 773g, so special care should be taken when moving a computer equipped with CNPS7000-Cu.
