SKU: 800-11703F
  • Integrated Graphics - VGA
  • Max 4TB / 16 DIMM DDR5-4800 ECC RDIMM
  • 10x SATA 6Gb/s, 2x M.2
  • Up to 6x USB 3.1 G1, 3x USB 2.0
  • 4x PCIe 5.0 x16, 2x PCIe 5.0 x8
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

CPU Support
  • 4th Gen Intel Xeon Scalable processors
  • Socket E LGA 4677
Number of Processor (s)
Dual (Not Included)
Chipset
Intel C741
System Bios
AMI UEFI
Number of Memory Slots
16
Type of Memory Supported
DDR5-4800 ECC RDIMM
Maximum RAM
4TB
Back Panel I/O
  • 4 x USB 3.2 Gen1 Type-A
  • 1 x VGA
  • 1 x Serial port
  • 2 x RJ45 LAN
  • 1 x Dedicated IPMI LAN
Number of PCI/PCI Express Slots
  • 4 x PCIe 5.0 x16
  • 2 x PCIe 5.0 x8
Integrated SATA/SAS
  • 8 x SATA 6Gb/s via SlimSAS
  • 2 x SATA
# of M.2 Ports
2 x M.2 socket, with M key, type 2280/22110 support PCIe 4.0 x2 mode
Integrated Video
ASPEED AST2600
Integrated LAN
Broadcom BCM57416 Dual ports 10G LAN
IPMI
ASPEED AST2600 BMC
USB
  • 4 x USB 3.2 Gen1 Type-A on Back Panel I/O
  • 2 x USB 3.2 Gen1 Type-A via header
  • 1 x USB 2.0 onboard
  • 2 x USB 2.0 via header
Serial/Parallel Ports
  • 1 x Serial port on Back Panel I/O
  • 2 x Serial ports via header

    • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Compatible Accessories

    CPU

    Intel Xeon Silver 4410T 10-Core 2.7GHz w/26.25MB LGA4677 CPU (Tray)
    • 10x Cores / 20x Threads / Turbo Boost: 4.0 GHz
    • Supported Memory: DDR5-4000
    • Max # of PCIe 5.0 Lane: 80
    • TDP: 150W
    Manufacturer: Intel
    Mfg P/N: PK8071305121601
    Availability: Temporarily out of stock
    Intel Xeon Silver 4410Y 12-Core 2GHz w/30MB LGA4677 CPU (Tray)
    • 12x Cores / 24x Threads / Turbo Boost: 3.9 GHz
    • Supported Memory: DDR5-4000
    • Max # of PCIe 5.0 Lane: 80
    • TDP: 150W
    Manufacturer: Intel
    Mfg P/N: PK8071305120002
    Availability: Usually ships same day

    Memory

    Kingston 64GB DDR5-4800 ECC Reg CL40 2Rx4 288-pin RDIMM
    • PC5-38400
    • Dual-rank x4
    • ECC RDIMM
    Manufacturer: Kingston
    Mfg P/N: KSM48R40BD4TMM-64HMR
    Availability: Usually ships with 1-2 business days
