SKU: 800-11709C
  • Integrated Intel Graphics - DVI / HDMI / Display port / VGA
  • Max 32GB / 4 Dimm DDR3 1600/1333 ECC/Non-ECC Un-Buffered (UDIMM)
  • 8x SATA 6Gb/s / RAID 0, 1, 10, 5
  • Up to 6x USB 3.0, 10x USB 2.0 / 2x IEEE1394a
  • 2x PCIe X16, 3x PCIe X1, 2x PCI
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
    Socket 1150 for:
    • Intel Xeon E3-1200 v3 product family
    • Intel 4th generation Intel Core i3/i5/i7 processors
Number of Processor (s)
Single (Not Included)
Chipset
Intel C226 Chipset
System Bios
AMI BIOS
Video card slot
PCI-Express 3.0/2.0 X16
Number of Memory Slots
4
Type of Memory Supported
240-pin DDR3 1600/1333 ECC/Non-ECC Un-Buffered memory (UDIMM)
Maximum RAM
32 GB
Back Panel I/O
  • 1 x PS/2 keyboard/mouse combo port
  • 2 x USB 3.0
  • 4 x USB 2.0
  • 1 x DVI-D
  • 1 x DisplayPort
  • 1 x HDMI
  • 1 x VGA
  • 2 x RJ45 LAN ports
  • 1 x Audio I/O
Number of PCI/PCI-Express Slots
  • 2 x PCI-Express 3.0/2.0 X16 (X16 or dual X8)
  • 3 x PCI-Express X1
  • 2 x PCI
On-Board EIDE/Floppy
Not Available
Integrated SATA/SAS
  • 6 x SATA 6Gb/s through the Intel C226
  • 2 x SATA 6Gb/s through the ASM1061
Integrated SATA/SAS RAID
  • Intel C226: RAID 0, 1, 5 and 10
  • ASM1061: RAID 0 and 1
Integrated Audio
Realtek ALC1150 8-Channel High Definition Audio CODEC
Integrated Video
    Integrated Intel Graphics from:
    • Intel 12x5 v3 product family
        or
    • Intel 4th generation Intel Core i3/i5/i7 processors
Integrated LAN
Intel i217LM + Intel i210AT Gigabit LAN Controller
IPMI
Not Available
USB
    Up to 16 x USB ports:
    • 2 x USB 3.0 ports on Back Panel I/O
    • 4 x USB 3.0 ports via headers
    • 4 x USB 2.0 ports on Back Panel I/O
    • 6 x USB 2.0 ports via headers
IEEE 1394
2 x IEEE1394a via header
Serial/Parallel Ports
2 x Serial port via header
PS/2 Ports
1 x PS/2 keyboard/mouse combo port
Form Factor
ATX
Dimensions
12" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
