SKU: 540-17418
  • 2 computers can share 3 different USB peripherials.
  • Supports keyboard and mouse plug and play.
  • USB self-power operation.
  • 1920 x 1440 max resolution
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

Warranty
Standard Warranty
3 Year Limited
General Information
Manufacturer
StarTech.com
Manufacturer Part Number
SV231USB
Manufacturer Website Address
Brand Name
StarTech.com
Product Model
SV231USB
Product Type
Analog KVM Switch
Technical Information
Number of Computers
2
Number of Users
1 x Local User
Video Signals
  • VGA
  • SVGA
  • Graphics Resolution
    1920 x 1440
    Scan Intervals

    8, 15 and 30 Seconds

    Operating Range
    72"
    Cable Length
    2 x 72" USB Included
    Interfaces/Ports
    User/Console Ports
  • 1 x 15-pin HD-15 Female VGA
  • 3 x 4-pin Type A
  • Computer Ports
  • 2 x 15-pin HD-15 Male Video
  • 2 x 4-pin Type B USB
  • Physical Characteristics
    Color
    Black
    Form Factor
    Desktop
    Dimensions
    1.60" Height x 4.90" Width x 2.70" Depth
    Weight (Approximate)
    14.80 oz
    Miscellaneous
    Additional information

  • 2 computers can share 3 different USB peripherials
  • Front panel push buttons for easy computer selection
  • No drivers required for keyboard and mouse operation
  • Selectable auto scan time interval
  • Supports the latest DDC2B VGA monitors
  • USB self-power operation

  • System Requirements

    Console Side:

    • One VGA, SVGA or Multisync monitor
    • One USB keyboard
    • One USB mouse

    Computer Side:

    • Each USB enabled computer must be connected to the StarView switch by:
    • One HDB15 male-to-female VGA cable or monitor
    • One USB A-B cable with Type-A and Type-B plug for
    • USB devices, as shown in figure 1.

    Compatibility

    Plug and Play

    Platform Support
  • PC
  • Mac
  • Sun
  • Linux
  • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    • Warranty Length: 1 year
    • Warranty Provider: StarTech
    • Service Contact:
      1. First 30-day from invoice date: Allstarshop On-line RMA Request
      2. After 30-day from invoice date: Contact StarTech at (519) 455-4931
    • Technical Support: StarTech (519) 455-4931

    Package Contents


    • 2 Port Professional USB KVM Switch Kit with Cables
    • 1 x Instruction Guide
    • 1 x Power Adapter
    • 2 x 2-in-1 USB/Monitor Cables
