SKU: 331-26029A
  • Resolution: 1920 x 1080
  • Brightness: 264-300 cd/m2
  • Contrast Ratio: 1000:1
  • Response Time: 12ms
  • 1 x VGA / 1 x HDMI / 1 x DisplayPort / USB 2.0
Our Price: Login to see price
Availability: Temporarily out of stock


Specifications

Viewable Area
27" (16:9)
Brightness
264-300 cd/m2
Contrast Ratio
5000:1
Response Time
12ms
Viewing Angle
  • Horizontal: 178
  • Vertical: 178
  • Pixel Pitch
    0.2715mm
    Resolution
    1920 x 1080
    Analog Input
    1 x VGA
    Digital Input
    1 x DisplayPort
    HDMI Input
    1 x HDMI
    Built in Speakers
    2 x 2W
    Built-in USB Hub
    2 x USB 2.0
    Power Consumption
  • Normal: 35W
  • Standby: < 1W
  • Dimensions
  • With Stand: 26.48" x 16.47" x 1.95"
  • Without Stand: 26.48" x 16.47" x 1.95"
  • Wall Mount (VESA)
    100 x 100mm
    General Information
    Manufacturer
    Planar Systems, Inc
    Manufacturer Part Number
    997-6848-00
    Manufacturer Website Address
    Brand Name
    Planar
    Product Line
    Helium
    Product Model
    PCT2785
    Product Type
    LCD Touchscreen Monitor
    Technical Information
    Screen Size
    27"
    Screen Mode
    Full HD
    Response Time
    12 ms
    Aspect Ratio
    16:9
    Horizontal Viewing Angle
    178°
    Vertical Viewing Angle
    178°
    Adjustable Display Angle
    Yes
    Backlight Technology
    Edge LED
    Video
    Maximum Resolution
    1920 x 1080
    Color Supported
    16.7 Million Colors
    Contrast Ratio
    5,000:1
    Brightness
    264 Nit
    Audio
    Speakers
    Yes
    Touchscreen Information
    Touchscreen
    Yes
    Touchscreen Type
    Projected Capacitive
    Multi-touch Screen
    Yes
    Interfaces/Ports
    HDMI
    Yes
    USB
    Yes
    Headphone
    Yes
    DisplayPort
    Yes
    Built-in Devices
    Built-in Devices
  • Microphone
  • USB Hub
  • Speaker
  • Webcam
  • Power Description
    Input Voltage
  • 110 V AC
  • 220 V AC
  • Physical Characteristics
    VESA Mount Compatible
    Yes
    VESA Mount Standard
    100 x 100
    Color
    Black
    Height
    16.5"
    Depth
    2"
    Miscellaneous
    Certifications & Standards
    • UL/cUL
    • FCC
    • CE
    • TUV
    Platform Supported
    PC
    Green Compliant
    Yes
    Green Compliance Certificate/Authority
    RoHS

    The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    • Warranty Length: 3 years
    • Warranty Provider: Planar
    • Service Contact:
      1. First 30-day from invoice date: Allstarshop On-line RMA Request
      2. After 30-day from invoice date: Contact Planar at 866-752-6271
    • Technical Support: Planar 866-752-6271

    Package Contents

    • PCT2785 27" Wide Multi-Touch Monitor
    • Power Cord
    • VGA Cable
    • HDMI Cable
    • USB Cable (A to B)
    • Audio-in Cable
    • User’s Guide
    • Cleaning Cloth
    • Stylus
