Gigabyte Z890 EAGLE WIFI7 Z890 LGA1851 ATX Motherboard

Support: (626) 854-9338

Gigabyte Z890 EAGLE WIFI7 Z890 LGA1851 ATX Motherboard

SKU:	800-58081F

Integrated Intel Graphics - DisplayPort, USB4 Type-C
Max 256GB / 4x DDR5 DIMM / Up to 8800+ (O.C.)
4x SATA 6GB/s, 4x M.2 / RAID 0, 1, 10, 5
Up to 1x USB4 (USB-C), 3x USB 3.2 G2 (1x USB-C), 5x USB 3.2 G1, 8x USB 2.0
1x PCIe 5.0 x16, 2x PCIe 4.0 x16 (x4)

Our Price:	Login to see price
Availability:	Temporarily out of stock

Accessories

: Intel Core Ultra 5 245K 14-Core LGA1851 w/24MB cache CPU (BOX)

: Intel Core Ultra 7 265K 20-Core LGA1851 w/30MB cache CPU (BOX)

: Intel Core Ultra 9 285K 24-Core LGA1851 w/36MB cache CPU (BOX)

Designed for gamers, the matte black Z890 EAGLE WIFI7 LGA 1851 ATX Motherboard from Gigabyte supports Intel Core Ultra Series 2 processors that fit into the LGA 1851 socket. With four DDR5 slots, one PCIe 5.0 x16 slot with UD, two PCIe 4.0 x16/x4 slots, one M.2 25110/22110/2580/2280 PCIe slot, two 22110/2280 PCIe slots, one M.2 22110/2280 PCIe/SATA slot, and four SATA III 6 Gb/s slots, you'll be able to build a powerful gaming rig. With EZ-Latch Plus and Click, installing a graphics card and M.2 SSDs with heat sinks is user-friendly and doesn't require tools. For online connectivity, the motherboard provides fast connectivity with 2.5GbE LAN and Wi-Fi 7 (802.11be). Other integrated features include Bluetooth 5.4, support for up to 256GB of DDR5 memory with XMP support, automatic AI overclocking, and more.

Description

Specifications

CPU Support

LGA1851 socket for Intel Core Ultra Processors (Series 2)

Number of Processor (s)

Single (Not Included)

Chipset

Intel Z890 chipset

System Bios

UEFI AMI BIOS

Video card slot

PCIe 5.0 x16

Number of Memory Slots

Type of Memory Supported

DDR5-8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200 / 5000 / 4800 Non-ECC, Un-buffered Memory

Maximum RAM

256GB

Back Panel I/O

1 x USB4 Type-C port
2 x USB 3.2 Gen2 Type-A ports
3 x USB 3.2 Gen1 Type-A ports
4 x USB 2.0
1 x DisplayPort
1 x RJ45 LAN
1 x Audio I/O
2 x Antenna connectors (2T2R)

Number of PCI/PCI-Express Slots

1 x PCIe 5.0 x16
2 x PCIe 4.0 x16 (x4 electrical)

Integrated SATA/SAS

4 x SATA 6Gb/s

# of M.2 Ports

1 x M.2 with M key, type 2280/2580/22110/25110 supports PCIe 5.0 x4 mode
2 x M.2 with M key, type 2280/22110 support PCIe 4.0 x4 mode
1 x M.2 with M key, type 2280/22110 supports PCIe 4.0 x4 & SATA mode

Integrated SATA/SAS RAID

RAID 0, 1, 10, 5

Integrated Audio

Realtek 7.1 CH HD Audio Codec

Integrated Video

Integrated Graphics from processor (Actual support may vary by CPU)

Integrated LAN

Realtek 2.5Gb Ethernet

Integrated Wifi

Wi-Fi 7 (802.11be) & Bluetooth v5.4

USB

1 x USB4 Type-C port on Back Panel I/O
1 x USB 3.2 Gen2 Type-C port via header
2 x USB 3.2 Gen2 Type-A ports on Back Panel I/O
3 x USB 3.2 Gen1 Type-A ports on Back Panel I/O
2 x USB 3.2 Gen1 ports via header
4 x USB 2.0 on Back Panel I/O
4 x USB 2.0 via headers

Form Factor

ATX

Dimensions

12" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 3 years
Warranty Provider: Gigabyte
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Gigabyte at (626) 854-9338 Or visit Gigabyte customer service online.
Technical Support: Gigabyte (626) 854-9338 or visit Gigabyte technical support online.
