Asus ROG MAXIMUS Z790 HERO Z790 LGA1700 ATX Motherboard

Support: (812)282-2787

Asus ROG MAXIMUS Z790 HERO Z790 LGA1700 ATX Motherboard

SKU:	800-51180C

Integrated Intel Graphics - HDMI / 2x Thunderbolt 4 USB-C
Max 128GB / 4x DDR5 DIMM / Up to 7200(O.C.)
6x SATA 6Gb/s, 5x M.2 / RAID 0, 1, 5, 10
2x Thunderbolt 4 USB-C, 11x USB 3.2 G2 (2x USB-C), 4x USB 3.2 G1, 4x USB 2.0
2x PCIe 5.0 x16, 1x PCIe 4.0 x16

Our Price:	Login to see price
Availability:	Usually ships same day

Accessories

: Kingston Fury Beast 32GB Kit (2x 16GB) DDR5-6000 CL40 288-pin DIMM

: Kingston Fury Beast 64GB Kit DDR5-5600 CL40 288-pin DIMM

: Crucial P3 Plus 1TB NVMe PCIe 4.0 M.2 SSD

The ROG Maximus Z790 Hero offers a 20+1 teamed power stage topology to power the CPU Vcore and onboard graphics processor. Each power stage is rated for up to 90A of output, and they provide the smoothest possible power delivery to the processor, even under the highest loads.

Description

Specifications

CPU Support

LGA1700 socket for 14th, 13th & 12th Generation Intel Core Processors

Number of Processor (s)

Single (Not Included)

Chipset

Intel Z790 chipset

System Bios

UEFI AMI BIOS

Video card slot

PCIe 5.0 x16

Number of Memory Slots

Type of Memory Supported

DDR5-7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600 / 5400 / 5200/ 5000/ 4800MHz Non-ECC, Un-buffered Memory

Maximum RAM

128GB

Back Panel I/O

2 x Thunderbolt 4 USB Type-C ports
1 x USB 3.2 Gen2 Type-C port
5 x USB 3.2 Gen2 Type-A ports
4 x USB 3.2 Gen1 Type-A ports
1 x HDMI
1 x RJ45 LAN
1 x Audio I/O
1 x Wi-Fi Module

Number of PCI/PCI-Express Slots

2 x PCIe 5.0 x16 (single x16, dual x8/x8)
1 x PCIe 4.0 x16 (max x4)

Integrated SATA/SAS

6 x SATA 6Gb/s

# of M.2 Ports

1 x M.2 socket, with M key, type 2242/2260/2280/22110 supports PCIe 4.0 x4 mode
1 x M.2 socket, with M key, type 2242/2260/2280/22110 supports PCIe 5.0 x4 mode (Hyper M.2_1 slot)
1 x M.2 socket, with M key, type 2242/2260/2280 supports PCIe 4.0 x4 mode
1 x M.2 socket, with M key, type 2242/2260/2280 supports PCIe 4.0 x4 & SATA mode
1 x M.2 socket, with M key, type 2242/2260/2280/22110 supports PCIe 4.0 x4 mode (Hyper M.2_2 slot)

Integrated SATA/SAS RAID

RAID 0, 1, 5, 10

Integrated Audio

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC

Integrated Video

Integrated Intel Graphics from processor

Integrated LAN

Intel 2.5Gb Ethernet

Integrated Wifi

2x2 Wi-Fi 6E & Bluetooth v5.3

USB

2 x Thunderbolt 4 USB Type-C ports on Back Panel I/O
1 x USB 3.2 Gen 2x2 Type-C port via header
1 x USB 3.2 Gen2 Type-C port on Back Panel I/O
5 x USB 3.2 Gen2 Type-A ports on Back Panel I/O
4 x USB 3.2 Gen2 Type-A ports via header
4 x USB 3.2 Gen1 Type-A ports on Back Panel I/O
4 x USB 2.0 via headers

Form Factor

ATX

Dimensions

12" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 1 year
Warranty Provider: Asus
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Asus at (510)739-3777 Or visit Asus customer service online.
Technical Support: Asus (812)282-2787 or visit Asus technical support online.
