Asus Pro WS Z890-ACE SE Z890 LGA1851 ATX Motherboard

Support: (812)282-2787

Asus Pro WS Z890-ACE SE Z890 LGA1851 ATX Motherboard

SKU:	800-51145E

Integrated Intel Graphics - HDMI, Thunderbolt 4 USB-C
Max 192GB / 4x DDR5 DIMM / Up to 9066+ (O.C.)
4x SATA 6GB/s, 1x SlimSAS, 4x M.2 / RAID 0, 1, 10, 5
Up to 1x Thunderbolt USB-C, 8x USB 3.2 G2 (2x USB-C), 2x USB 3.2 G1, 4x USB 2.0
2x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4)

Our Price:	Login to see price
Availability:	Usually ships within 1-2 business days

Accessories

: Intel Core Ultra 5 245K 14-Core LGA1851 w/24MB cache CPU (BOX)

: Intel Core Ultra 7 265K 20-Core LGA1851 w/30MB cache CPU (BOX)

: Intel Core Ultra 9 285K 24-Core LGA1851 w/36MB cache CPU (BOX)

The Pro WS Z890-ACE SE empowers workstation users of all levels by maximizing the performance of the Intel Core Ultra Processor (Series 2) processors with 16+1+2+2 team power stages, DDR5 slots, PCIe 5.0 and lightning-fast connectivity including Thunderbolt 4 port, 10Gb and 2.5Gb Ethernet.

The workstation motherboard is engineered to support dual graphics cards, making it an ideal choice for content creation, AI and deep learning, and IT management.

Description

Specifications

CPU Support

LGA1851 socket for Intel Core Ultra Processors (Series 2)

Number of Processor (s)

Single (Not Included)

Chipset

Intel Z890 chipset

System Bios

UEFI AMI BIOS

Video card slot

PCIe 5.0 x16

Number of Memory Slots

Type of Memory Supported

DDR5-9066(O.C.)+ / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200 / 5000 / 4800 Non-ECC, Un-buffered Memory

Maximum RAM

256GB

Back Panel I/O

1 x Thunderbolt 4 USB Type-C port
1 x USB 3.2 Gen 2x2 Type-C port
6 x USB 3.2 Gen2 Type-A ports
1 x HDMI
1 x BMC VGA
3 x RJ45 LAN
1 x Audio I/O

Number of PCI/PCI-Express Slots

2 x PCIe 5.0 x16 (x16 or x8/x8)
1 x PCIe 4.0 x16 (x4 electrical)

Integrated SATA/SAS

4 x SATA 6Gb/s
1 x SlimSAS supports PCIe 4.0 x4 mode or up to 4 SATA (Cable Not Include)

# of M.2 Ports

1 x M.2 with M key, type 2260/2280 supports PCIe 5.0 x4 mode
2 x M.2 with M key, type 2242/2260/2280 supports PCIe 4.0 x4 mode
1 x M.2 with M key, type 2280 supports PCIe 4.0 x4 mode

Integrated SATA/SAS RAID

RAID 0, 1, 10, 5

Integrated Audio

Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC

Integrated Video

Integrated Graphics from processor (Actual support may vary by CPU)

Integrated LAN

Marvell AQtion 10Gb Ethernet
Intel 2.5Gb Ethernet
Realtek 1Gb Ethernet dedicated for AST2600

USB

1 x Thunderbolt 4 USB Type-C port on Back Panel I/O
1 x USB 3.2 Gen 2x2 Type-C port on Back Panel I/O
1 x USB 3.2 Gen 2x2 Type-C port via header
6 x USB 3.2 Gen2 Type-A ports on Back Panel I/O
2 x USB 3.2 Gen1 Type-A ports via header
4 x USB 2.0 via headers

Serial/Parallel Ports

1 x Serial port via header

Form Factor

ATX

Dimensions

12" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 3 years
Warranty Provider: Asus
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Asus at (510)739-3777 Or visit Asus customer service online.
Technical Support: Asus (812)282-2787 or visit Asus technical support online.
