Asus PRIME X670E-PRO WIFI AMD X670E Socket AM5 ATX Motherboard

Support: (812)282-2787

Asus PRIME X670E-PRO WIFI AMD X670E Socket AM5 ATX Motherboard

SKU:	800-51169E

Integrated Radeon Graphics - HDMI / DisplayPort
Max 192GB / 4x DDR5 DIMM / Up to 8000+ (O.C.)
4x SATA 6GB/s, 4x M.2 / RAID 0, 1, 10
Up to 6x USB 3.2 G2 (3x USB-C), 7x USB 3.2 G1 (1x USB-C), 6x USB 2.0
1x PCIe 5.0 x16, 1x PCIe 4.0 x16, 1x PCIe 4.0 x4

Our Price:	Login to see price
Availability:	Usually ships within 1-2 business days

Accessories

: AMD RYZEN 5 7600X 6-Core 4.7GHz /6MB cache AM5 CPU (Retail)

: AMD Ryzen 7 7700X 8-Core 4.5GHz /8MB cache AM5 CPU (Retail)

: AMD Ryzen 9 7900X 12-Core 4.7GHz /12MB cache AM5 CPU (Retail)

Prime X670E-Pro WiFi support for DDR5, PCIe 5.0 x16 slot, and PCIe 5.0 M.2 slot, this is a cost-effective option for anyone building out a next-gen PC. WiFi 6E, a Realtek 2.5Gb Ethernet port, and a Thunderbolt 4 header all add to its already-impressive value proposition. Its pre-mounted I/O shield streamlines the installation process, it features Asus PCIe Slot Q-Release button that takes the hassle out of removing a graphics card, and its Q-LED diagnostic array takes the guesswork out of troubleshooting.

Description

Specifications

CPU Support

AMD Ryzen 9000/ 8000/7000 series processors

Number of Processor (s)

Single (Not Included)

Chipset

AMD X670E

System Bios

UEFI AMI BIOS

Video card slot

PCIe 5.0 x16

Number of Memory Slots

Type of Memory Supported

DDR5-8000+(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory

Maximum RAM

192GB

Back Panel I/O

1 x USB 3.2 Gen 2x2 Type-C port
1 x USB 3.2 Gen2 Type-C port
3 x USB 3.2 Gen2 Type-A ports
1 x USB 3.2 Gen1 Type-C port
4 x USB 3.2 Gen1 Tupe-A ports
1 x HDMI
1 x DisplayPort
1 x RJ45 LAN
1 x Audio I/O
1 x Wi-Fi Module

Number of PCI/PCI-Express Slots

1 x PCIe 5.0 x16
1 x PCIe 4.0 x16 (max x4)
1 x PCIe 4.0 x4

Integrated SATA/SAS

4 x SATA

# of M.2 Ports

1 x M.2 socket, with M key, type 2242/2260/2280 supports PCIe 5.0 x4 mode
2 x M.2 socket, with M key, type 2242/2260/2280 supports PCIe 4.0 x4 mode
1 x M.2 socket, with M key, type 2242/2260/2280/22110 supports PCIe 3.0 x4 & SATA mode

Integrated SATA/SAS RAID

RAID 0, 1, 10

Integrated Audio

Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC

Integrated Video

Integrated Graphics from processor (Actual support may vary by CPU)

Integrated LAN

Realtek 2.5 Gb Ethernet

Integrated Wifi

2x2 Wi-Fi 6E

USB

1 x USB 3.2 Gen 2x2 Type-C port on Back Panel I/O
1 x USB 3.2 Gen2 Type-C port on Back Panel I/O
1 x USB 3.2 Gen2 Type-C port via header
3 x USB 3.2 Gen2 Type-A ports on Back Panel I/O
1 x USB 3.2 Gen1 Type-C port on Back Panel I/O
2 x USB 3.2 Gen1 Type-A port via header
4 x USB 3.2 Gen1 Type-A ports on Back Panel I/O
6 x USB 2.0 via header

Form Factor

ATX

Dimensions

12" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 3 years
Warranty Provider: Asus
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
  This item is returnable for replacement only. It can only be exchanged with the same item.
2. After 30-day from invoice date: Contact Asus at (510)739-3777 Or visit Asus customer service online.
Technical Support: Asus (812)282-2787 or visit Asus technical support online.
