SKU: A320030
  • Resolution up to 1920 x 1200
  • Dual console operation
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

General Information
Manufacturer
Aten Technologies
Manufacturer Part Number
CE770
Brand Name
Aten
Product Line
ProXime
Product Model
CE770
Product Type
KVM Console/Extender
Technical Information
Number of Computers
1
Number of Users
  • 1 x Local
  • 1 x Remote
    • Video Signals
    WUXGA
    Graphics Resolution
    1920 x 1200 @ 60 Hz
    Operating Range
  • 492 ft - at 1920 x 1200
  • 984 ft - at 1280 x 1024
    • Interfaces/Ports
    User/Console Ports
  • 1 x 15-pin HD-15 Female Video Local User
  • 2 x Type A Female USB Local User
  • 1 x Mini-phone Stereo Female Speaker Local User
  • 1 x Mini-phone Stereo Female Microphone Local User
  • 1 x 15-pin HD-15 Female Video Remote User
  • 2 x Type A Female USB Remote User
  • 1 x Mini-phone Stereo Female Speaker Remote User
  • 1 x Mini-phone Stereo Female Microphone Remote User
    • Computer Ports
  • 1 x 17-pin SPHD-17 Female Keyboard/Mouse/Video
  • 1 x Mini-phone Stereo Female Speaker
  • 1 x Mini-phone Stereo Female Microphone
    • Other Ports
  • 1 x 9-pin DB-9 Male RS-232 Serial Receiver
  • 1 x 9-pin DB-9 Female RS-232 Serial Transmitter
  • 1 x RJ-45 Female Network Receiver
  • 1 x RJ-45 Female Network Transmitter
    • Physical Characteristics
    Form Factor
    Rack-mountable
    Dimensions
    0.98" Height x 3.15" Width x 7.87" Depth
    Weight (Approximate)
  • 1.08 lb - Transmitter
  • 1.06 lb - Receiver

    • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents


    • CE770 KVM Console/Extender
    • 2 x Power Adapter
    • 1 x Rack Mount Kit
    • 2 x Grounding Wires
    • 1 x User Manual
    • 1 x Quick Start Guide
    • 1 x USB KVM Cable (1.8m)
