SKU: A320028
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

General Information
Manufacturer
Aten Technologies
Manufacturer Part Number
CE700A
Brand Name
Aten
Product Line
ProXime
Product Model
CE700A
Product Type
KVM Console/Extender
Technical Information
Number of Computers
1
Number of Users
  • 1 x Local
  • 1 x Remote
    • Video Signals
    WUXGA
    Graphics Resolution
    1920 x 1200 @ 60 Hz
    Operating Range
  • 492 ft - at 1280 x 1024
  • 328 ft - at 1600 x 1200
  • 98 ft - at 1920 x 1200
    • Interfaces/Ports
    User/Console Ports
  • 1 x 15-pin HD-15 Female Video Local User
  • 2 x Type A Female USB Local User
  • 1 x 15-pin HD-15 Female Video Remote User
  • 2 x Type A Female USB Remote User
    • Computer Ports
    1 x SPHD-17 Female Keyboard/Mouse/Video
    Other Ports
  • 1 x RJ-45 Female Network Transmitter
  • 1 x RJ-45 Female Network Receiver
    • Power Description
    Input Voltage
    5.3 V DC
    Environmental Conditions
    Temperature
  • 32°F (0°C) to 122°F (50°C) Operating
  • -4°F (-20°C) to 140°F (60°C) Storage
    • Humidity
    0 to 80% Non-condensing Relative Humidity
    Physical Characteristics
    Form Factor
    Rack-mountable
    Dimensions
    0.98" Height x 3.21" Width x 4.92" Depth
    Weight (Approximate)
  • 11.29 oz - Transmitter
  • 10.93 oz - Receiver

    • The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

    Warranty and Service

    Package Contents


    • 1x CE700AL USB KVM Extender (Local Unit)
    • 1x CE700AR USB KVM Extender (Remote Unit)
    • 2 x Power Adapters
    • 1 x USB KVM Cable
    • 2 x Grounding Wires
    • 1 x Rack Mount Kit
    • 1 x User Manual
    • 1 x Quick Start Guide
