Thermaltake SMART SP-1000M 1000W PSU (Modular) - (Discontinued)

Support: (800)988-1088

Thermaltake SMART SP-1000M 1000W PSU (Modular) - (Discontinued)

SKU:	992-63120A

80 PLUS Bronze Certified: 82-88% Efficiency
2 x +12V Rail
6 x 8-pin (6+2) PCI-E Connector
MTBF: 100,000 hours minimum

Our Price:	Login to see price
Discontinued	- Not orderable

What's New

: WD Red SN700 PCIe 3.0 x4 NVMe M.2 2280 SSD - 2TB

: WD Red SN700 PCIe 3.0 x4 NVMe M.2 2280 SSD - 1TB

: AMD EPYC 9105 8-Core 3.95GHz 64MB Cache CPU (Tray)

In a computing world of new video and audio cards, add-ons, higher-powered chips and more, the search for power goes ever on. Thermaltake SMART M Series SP-1000M satisfies your power-hungry virtual instincts, and keeps you running at your best.

The PSU is ready for your SLI or CrossFire configuration with 4 x 8Pin PCIe connectors. Keeping it cool is a 14mm fan with RPM control. With its 80 PLUS BRONZE certification, less energy is wasted as heat or interference, delivering more power to your hungry system!

Output Connectors

20+4-pin Main Power x 1	4-pin+4 12V x 1


SATA x 12	4-pin Peripheral x 6	4-pin Floppy x 1	8-pin (6+2)pin PCI-E x 6

Description

20+4-pin Main Power x 1	4-pin+4 12V x 1


SATA x 12	4-pin Peripheral x 6	4-pin Floppy x 1	8-pin (6+2)pin PCI-E x 6

Specifications

Efficiency

88%

MTBF

100000 Hour

Current

13A

Frequency

50Hz-60Hz

Output Power

1000 W

Output Voltage

Output Voltage	Output Current
+3.3V	30A
+5V	30A
+12V1	40A
+12V2	80A
-12V	0.8A
+5Vsb	3A

Input Voltage

100V-240V

Connectors

1 x 24-pin Main Connector

1 x 8-pin 12V

6 x 6+2-pin PCI-E

12 x SATA

6 x Peripheral

1 x Floppy

Dimensions

150mm x 86mm x 160mm

General Information

Manufacturer

Thermaltake

Manufacturer Part Number

SP-1000M

Manufacturer Website Address

www.thermaltakeusa.com

Product Model

SP-1000M

Product Type

ATX12V & EPS12V Power Supply

Technical Information

Power Factor Correction (PFC)

Active

Number of Fans

Protection Type

Over Current

Under Voltage

Over Loading

Over Power

Short Circuit

Over Voltage

Modular

Yes

ATI CrossFire Supported

Yes

NVIDIA SLI Supported

Yes

Power Description

Input Voltage Type

Input Voltage Range

100 V AC to 240 V AC

Number of +12V Rails

Input Current

13 A @110 V AC/5 A @220 V AC

Interfaces/Ports

Receptacles

1 x 4-pin SP4 Floppy Drive

6 x 6+2pin PCI-E

6 x 4-pin LP4 Peripheral Device

1 x 24-pin ATX Motherboard

1 x 4+4pin ATX12V Motherboard

1 x 8-pin EPS12V Motherboard

12 x Serial ATA

Physical Characteristics

Form Factor

Internal

Height

3.4"

Depth

6.3"

Miscellaneous

Green Compliant

Yes

Green Compliance Certificate/Authority

80 Plus Bronze

RoHS

WEEE

Energy Star 5.0

ErP Ready

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

Warranty Length: 5 years
Warranty Provider: Thermaltake
Service Contact:
1. First 30-day from invoice date: Allstarshop On-line RMA Request
2. After 30-day from invoice date: Contact Thermaltake at (800)988-1088 Or visit Thermaltake customer service online.
Technical Support: Thermaltake (800)988-1088 or visit Thermaltake technical support online.

Package Contents

Thermaltake SMART Series SP-750 750W PSU
Modular Cables
Mounting Screws
Power Cord
