SKU: 800-51176C
  • Max 128GB / 4x DDR4 DIMM / Up to 4600(O.C.)
  • 4x SATA 6GB/s, 2x M.2 / RAID 0, 1, 10
  • Up to 2x USB 3.2 G2 (1x USB-C), 6x USB 3.2 G1, 5x USB 2.0
  • 1x PCIe x16, 1xPCIe x4, 1x PCI
Our Price: Login to see price
Discontinued - Not orderable


Specifications

CPU Support
  • AMD AM4 Socket for AMD Ryzen 5000 Series / 3000 Series
  • Not Compatible with AMD Ryzen 5 3400 G and Ryzen 3200 G
Number of Processor (s)
Single (Not Included)
Chipset
AMD B550
System Bios
AMI UEFI BIOS
Video card slot
PCIe 4.0/3.0 x16
Number of Memory Slots
4
Type of Memory Supported
DDR4-4600(O.C) / 4400(O.C) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
Maximum RAM
128GB
Back Panel I/O
  • 1 x PS/2 keyboard
  • 1 x PS/2 mouse
  • 1 x USB 3.2 Gen2 Type-A
  • 1 x USB 3.2 Gen2 Type-C
  • 2 x USB 3.2 Gen1 Type-A
  • 2 x USB 2.0
  • 2 x DisplayPort
  • 1 x HDMI
  • 1 x RJ45 LAN
  • 1 x Audio I/O
Number of PCI/PCI-Express Slots
  • 1 x PCIe 4.0 x16
  • 1 x PCIe 3.0 x4
  • 1 x PCI
Integrated SATA/SAS
4 x SATA 6Gb/s
# of M.2 Ports
  • 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 supports PCIE 4.0 x4 and SATA modes storage devices
  • 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 supports PCIE 3.0 x4 and SATA modes storage devices
Integrated SATA/SAS RAID
RAID 0, 1, 10
Integrated Audio
Realtek ALC887/897 7.1 Surround Sound HD Audio CODEC
Integrated Video
Integrated Graphics from processor (Actual support may vary by CPU)
Integrated LAN
Realtek RTL8111H Gigabit LAN
USB
  • 1 x USB 3.2 Gen2 Type-A on Back Panel I/O
  • 1 x USB 3.2 Gen2 Type-C on Back Panel I/O
  • 2 x USB 3.2 Gen1 Type-A on Back Panel I/O
  • 4 x USB 3.2 Gen1 via header
  • 2 x USB 2.0 on Back Panel I/O
  • 3 x USB 2.0 via heders
Serial/Parallel Ports
1 x Serial port via header
PS/2 Ports
  • 1 x PS/2 keyboard
  • 1 x PS/2 mouse
Form Factor
Micro ATX
Dimensions
9.6" x 9.6"

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.

Warranty and Service

  • Warranty Length: 3 years
  • Warranty Provider: Allstarshop.com
  • Service Contact: Allstarshop On-line RMA Request.
  • Technical Support: Asus (812)282-2787 or visit Asus technical support online.

Package Contents

  • Asus PRO B550M-C/CSM motherboard
  • Quick Installation Guide
  • Supporting DVD
  • I/O Shield
  • 2 x SATA 6Gb/s cables
  • 3 x M.2 SSD screw
  • 2 x M.2 SSD Hex screw
