SKU: 800-51135F
  • Integrated Radeon Graphics - HDMI, 1x DisplayPort
  • Max 256GB / 4x DDR5 DIMM / Up to 8000+ (O.C.)
  • 4x SATA 6GB/s, 3x M.2 / RAID 0, 1, 10, 5
  • Up to 4x USB 3.2 G2 (1x USB-C), 5x USB 3.2 G1 (1x USB-C), 8x USB 2.0
  • 1x PCIe 5.0 x16. 1x PCI 4.0 x16 (x4)
Our Price: Login to see price
Availability: Usually ships within 1-2 business days


Specifications

CPU Support
AMD Ryzen 9000/8000/7000 series processors
Number of Processor (s)
Single (Not Included)
Chipset
AMD B850
System Bios
UEFI BIOS
Video card slot
PCIe 4.0 x16
Number of Memory Slots
4
Type of Memory Supported
Up to DDR5-8000(O.C)+ Non-ECC, Un-buffered Memory
Maximum RAM
256GB
Back Panel I/O
  • 1 x USB 3.2 Gen2 Type-C port
  • 3 x USB 3.2 Gen2 Type-A ports
  • 2 x USB 3.2 Gen1 Type-A ports
  • 2 x USB 2.0 Type-A ports
  • 1 x DisplayPort
  • 1 x HDMI
  • 1 x Wi-Fi module
  • 1 x RJ45 LAN
  • 1 x Audio I/O
Number of PCI/PCI-Express Slots
  • 1 x PCI x16:
    • AMD Ryzen 9000 & 7000: PCIe 5.0 x16
    • AMD Ryzen 8000: PCIe 4.0 x16 (x8/x4 electrical)
  • 1 x PCIe 4.0 x16 (x4 electrical)
  • 2 x PCIe 3.0 x16 (x1 electrical)
Integrated SATA/SAS
4 x SATA 6Gb/s
# of M.2 Ports
  • 2 x M.2 2280:
    • AMD Ryzen 9000 & 7000:
      • 1 x M.2 with M key, type 2280 supports PCIe 5.0 x4 mode
      • 1 x M.2 with M key, type 2280 supports PCIe 4.0 x4 mode
    • AMD Ryzen 8000:
      • 1 x M.2 with M key, type 2280 supports PCIe 4.0 x4 mode
      • 1 x M.2 with M key, type 2280 supports PCIe 4.0 x4/x2 mode
  • 1 x M.2 with M key, type 2242/2260/2280 support PCIe 4.0 x4 mode
Integrated SATA/SAS RAID
  • Ryzen 9000 Series Processors: RAID 0/1/5/10
  • Ryzen 8000 Series Processors: RAID 0/1
  • Ryzen 7000 Series Processors: RAID 0/1/10
Integrated Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC
Integrated Video
Integrated Graphics from processor (Actual support may vary by CPU)
Integrated LAN
Realtek 2.5Gb Ethernet
Integrated Wifi
2x2 Wi-Fi 6E (802.11ax) & Bluetooth v5.3
USB
  • 1 x USB 3.2 Gen2 Type-C port on Back Panel I/O
  • 3 x USB 3.2 Gen2 Type-A ports on Back Panel I/O
  • 2 x USB 3.2 Gen1 Type-A ports on Back Panel I/O
  • 1 x USB 3.2 Gen1 Type-C port via header
  • 2 x USB 3.2 Gen1 Type-A ports via header
  • 2 x USB 2.0 Type-A ports on Back Panel I/O
  • 6 x USB 2.0 Type-A ports via headers

The above specifications are For reference only. Please contact the original manufacturer For the most updated specifications.
